BMS Transformer

BMS Transformer

Overview of Features

Low loss

High safety distance suitable for 1500V operating voltage environments

Applications：

New energy, energy storage battery management systems.

Data Download

Item number: TB1015G

Dimensions: 7.6*6.75*5.25mm

Topology: TR+CMC

Channels: 1

PIN No.: 6

PIN Pitch: 2.54mm

Array Pitch: 9.45mm

AEC-Q200 Grade: Y

TB1015G

Data Download

Item number: TE1011G

Dimensions: 14.8*11.7*4.85mm

Topology: TR+CMC

Channels: 2

PIN No.: 12P

PIN Pitch: 2.0mm

Array Pitch: 14.7mm

AEC-Q200 Grade: Y

TE1011G

Item number: TB1013G

Dimensions: 7.6*6.75*5.25mm

Topology: TR+CMC

Channels: 1

PIN No.: 6P

PIN Pitch: 2.54mm

Array Pitch: 9.45mm

AEC-Q200 Grade: Y

TB1013G

Data Download

Item number: TB1121G

Dimensions: 8.50*13.31*5.75mm

Topology: TR

Channels: 1

PIN No.: 6P

PIN Pitch: 2.54mm

Array Pitch: 16.85mm

AEC-Q200 Grade: Y

TB1121G

Item number: TB1016G

Dimensions: 8.50*13.31*5.75mm

Topology: TR

Channels: 1

PIN No.: 6P

PIN Pitch: 2.54mm

Array Pitch: 16.85mm

AEC-Q200 Grade: Y

TB1016G

Data Download

Item number: TB1023G

Dimensions: 8.38*7.69*4.25mm

Topology: CMC+TR

Channels: 1

PIN No.: 6P

PIN Pitch: 2.54&3.81mm

Array Pitch: 10.5mm

AEC-Q200 Grade: Y

TB1023G

Data Download

Item number: TB1022G

Dimensions: 8.38*7.69*4.25mm

Topology: CMC+TR

Channels: 1

PIN No.: 6P

PIN Pitch: 2.54&3.81mm

Array Pitch: 10.5mm

AEC-Q200 Grade: Y

TB1022G

Item number: TB101CG

Dimensions: 7.6*6.75*5.25mm

Topology: TR+CMC

Channels: 1

PIN No.: 6P

PIN Pitch: 2.54mm

Array Pitch: 9.45mm

AEC-Q200 Grade: Y

TB101CG
